Unilin Stonewool SW/RS 100mm Rainscreen Cladding

Unilin delivers a range of non-combustible stonewool insulation products with Euroclass 'A1' fire ratings, providing dependable performance when fire safety is a priority. This 100mm Unilin Stonewool SW/RS Ventilated Rainscreen Cladding performs excellently in ventilated facades, rainscreens, framing systems, and closed cavity applications such as curtain walling. The 100mm Stonewool SW/RS Rainscreen Cladding insulation provides a robust, uniform, high-density performance that resists damage during construction, particularly when mechanical fixings are used.

Product Details

Brand: Unilin ®

Model: 100mm Unilin SW/RS Rainscreen Cladding insulation

Thickness: 100mm

Length: 1200mm

Width: 600mm

Board Coverage: 0.72m²

Pack Coverage: 1.44m2

Pack Quantity: 2

Pack Weight: 18kg

Dimensions: 1,200mm x 600mm x 100mm

Density: 45kg/m3

Type: Non Combustible A1 Euroclass Stonewool Insulation Slab

Profile: Square Edge

R-Value: 2.85 m2K/W

Thermal Conductivity: 0.035W/mK

Fire Classification: Euroclass A1

Finish: Unfaced

Application Temperature: from +5 °C to +25 °C

Shipping method: Articulated Vehicle ǀ Courier

Application: Insulation for Ventilated Rainscreen Cladding

Features: Non-combustible A1 stone wool insulation slab

Advantages:

1. Achieves Euroclass A1 Fire classification.
2. Features a strong, high-density construction.
3. Improves acoustic insulation capabilities.
4. Suitable for use in tall residential and commercial buildings.
5. 100mm stonewool Rainscreen Cladding Insulation

About

Rainscreen cladding at 100mm thickness is an essential element in contemporary building construction. It functions as a weather-resistant barrier and supports both energy conservation and indoor thermal regulation. This insulation type installs behind the exterior cladding, creating an air gap that allows ventilation between the outer cladding layer and the building fabric.

A key advantage of 100mm rainscreen cladding insulation lies in its moisture-handling capabilities. The ventilated cavity permits air movement, which prevents moisture accumulation and reduces the likelihood of dampness, decay, and structural deterioration. Enhanced moisture control also extends the durability of the building's outer envelope.

Installation

1. Unilin 100mm Stonewool panels arrive in polythene-wrapped bundles suitable for brief uncovered storage. For longer storage durations, keep bundles raised and protected from weather exposure. When specified within the system design, breathable membranes can provide additional protection. The high-density composition allows temporary exposure during installation, though standard construction practice recommends weather protection whenever possible.
2. Key considerations for working with 100mm Unilin SW/RS panels:
3. Panels are easy to handle and can be cut precisely with a fine-tooth saw or sharp utility knife. Accurate fitting between adjacent boards and around openings ensures maximum thermal performance.
4. Tight joints between adjoining panels maintain continuity throughout the insulation layer.
5. Install boards in a staggered bond pattern with all joints pulled tight.
6. Use metal and polypropylene 'mushroom' type fixings with a minimum 100mm diameter to secure panels until the main cladding is fitted.
7. Account for all penetrations through the insulation, particularly at floor levels and openings, in your thermal design calculations.

Handling, Cutting, and Storage:

1. Unilin Rainscreen Cladding Insulation should be placed on a clean, level, raised surface and kept under protective covering.
2. Note that polythene wrapping alone does not provide adequate weather protection.
3. Take care to prevent damage during storage and throughout the construction phase.
4. When handling the insulation board, always use appropriate personal protective equipment (PPE).

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.
