100mm Unilin ECO360/CW Partial Fill Cavity Wall PIR Board

100mm Unilin ECO360/CW Partial Fill Cavity Wall PIR Insulation Board provides a bio-enhanced, high-performance solution for partial-fill cavity wall insulation applications. Featuring robust facings, precision-engineered joints, preformed corners, and an exceptional Lambda value of 0.020 W/mK, this board delivers outstanding thermal performance.

The 100mm Unilin Partial Fill Cavity Wall PIR Insulation Board represents an environmentally responsible option for Passive and low-energy building projects. When installed in a standard cavity wall configuration, it can achieve an impressive Passive U-Value of 0.15 W/m2K.

Installing 100mm ECO360 Partial Fill Cavity Wall PIR Insulation Board allows you to maintain a residual cavity space that provides robust protection against wind-driven rain penetration, safeguarding your building structure.

Product Details

Model: Cavity Wall 360

Length: 1200mm

Width: 450mm

Thickness: 100mm

Pack Quantity: 4

Board Coverage: 0.54m2

Pack coverage: 2.16m2

Pack Weight: 8kg

Thermal Conductivity: 0.020W/mK

R-Value: 5m2K/W

Compressive Strength: 120kPa

Type: Bio enhanced high performance PIR Insulation

Inner facing: Foil facing

Outer facing: Foil facing

Applications: Partial fill cavity walls

Advantages:

1. Bio-enhanced eco-friendly 100mm PIR Insulation technology
2. Exceptional thermal performance with 0.020 W/mK thermal conductivity
3. Halogen-free composition for safety
4. Sustainable biodegradable packaging
5. Clear cavity space preservation for moisture management
6. Optimised Lambda value for improved U-Values
7. 100mm Partial Fill Insulation Board solution

Applications

1. Partial fill cavity walls

Handling, Cutting, and Storage:

1. Unilin Partial Fill Insulation should be positioned on a flat, clean surface elevated from ground level and protected with suitable covering.
2. Note that polythene wrapping alone does not provide adequate protection from weather exposure.
3. Take care to prevent damage to the insulation during storage and on-site handling.
4. Always use appropriate personal protective equipment (PPE) when working with insulation board.

Certification and Standards:

1. BBA Certification Number: 10/4803.
2. Compliance with BS EN ISO 9001 Quality Management System.
3. Adherence to BS EN ISO 14001 Environmental Management System.
4. Conformance with BS EN 13166 standards.

Info

Explore our comprehensive Unilin range and refine your selection by thickness or coverage using the filters on the left. For guidance on product suitability for your specific project or to request a bulk discount quotation, contact us via phone on +4402038839057, email sales@insulationbee, or use our Live Chat service - offering the most competitive UK Insulation board pricing.
