92.5mm Ultra Liner PIR Insulated Plasterboard

92.5mm Ultra Liner Insulated Plasterboard combines a high-performance PIR insulation layer with 12.5mm tapered edge plasterboard, delivering thermal insulation and drylining in one product. Ideal for internal walls, ceilings and pitched roofs in new build and refurbishment applications.

The PIR insulation core achieves a thermal conductivity of 0.022 W/mK, significantly improving U-values and energy efficiency across various wall and roof constructions.

With a rigid polyisocyanurate (PIR) core faced in kraft foil paper, this board can be fixed using drywall adhesive or mechanical fasteners. The flexible installation approach suits numerous internal wall and roof scenarios.

Ultra Liner insulated plasterboards minimise heat loss, enhance thermal performance and support sustainable building practices. Both board faces feature composite kraft foil facings with an integrated vapour control layer, reducing condensation risk whilst boosting thermal efficiency.

Ultra Liner boards work as an alternative to Sopratherm PL4000, Quinn Therm Laminate, XT/TL Thermal Liner, Gyproc Thermaline and Knauf Laminates.

Installation is straightforward—simply cut with a sharp knife or fine-toothed saw. Always wear appropriate PPE when handling or fitting insulated plasterboard.

Pack Size & Coverage

1. Brand: Ultra Liner®
2. Model: 92.5mm Ultra Liner PIR
3. Thickness: 92.5mm overall
4. Length: 2400mm
5. Width: 1200mm
6. Board m2: 2.88m2
7. Weight: 14.88kg
8. Density: 30-32 Kg/m3
9. Compressive Strength: 120 kPa
10. R-Value: 3.70 m2K/W
11. Thermal Conductivity: 0.022 W/mk
12. Material: PIR core ǀ Gypsum plasterboard
13. Vapour Resistivity: 100 MNs/gm
14. Finish: Composite Kraft facings
15. Shipping method: Articulated Vehicle ǀ Courier
16. Applications: Internal walls ǀ Pitched and flat roofs
17. Vapour Control Layer: Yes, build in
18. Fixing method: Adhesive bonding
19. ETA Notification: Yes
20. Features: Insulation and drylining in one board

Ultra Liner PIR Insulated Plasterboard – Key Features

• Combine insulation and plasterboard in a single board to save time and reduce installation costs.
• Thinner insulation layer maximises usable internal space.
• Integrated vapour control layer (VCL) minimises condensation.
• Works across many wall types, from masonry to solid construction.
• Three-in-one solution: insulation, vapour control and plasterboard.
• Suitable for refurbishment and new build projects alike.
• Simple installation—ready for plastering and finishing.
• Delivers effective thermal insulation and drylining simultaneously.
• Built-in Vapour Control Layer (VCL) boosts thermal performance.
• High-performance PIR core with 0.022 W/mK thermal conductivity.

Info

Explore our Ultra Liner insulation range. We deliver across the UK Mainland. For project advice, product suitability queries or bulk quotations, contact us on 02038839057 / 02038839057, email sales@insulationbee.co.uk or use Live Chat - Lowest UK Insulation Prices near me.
