CERESIT® CT325 is a reinforcing mesh engineered for embedding into reinforcing mortars as part of CERESIT External Thermal Insulation Composite Systems (ETICS). When protecting façades or pedestals that experience greater mechanical stress, consider applying Ceresit CT 325 across two layers or selecting a higher density mesh rated at 330 g/m². This product is supplied in a convenient 1.1 metre width with 50 metres of length per roll.

Product specification

• Roll width: 110 cm
• Roll length: 50 m
• Roll coverage: 55.00
• Weight/m2: 0.16kg
• Mesh size: 4x4mm
• Warp: 24x2 per 100 mm
• Weft: 22 per 100 mm
• Colour: Dark Green
• Base: E-Glass fabric
• Weave: gauze, which prevents movement of the grid
• Treated fabric weight: ≥160 g/m2
• Mesh square dimensions: 4.0 mm × 4.0 mm
• Standard condition: 2075 N/5cm 2180 N/5cm
• After 28 days in 5 % NaOH: 1195 N/5cm 1220 N/5cm
• Longitudinal elongation: < 3.3 %
• Lateral elongation: < 2.7 %
• Amount required: approx. 1.1 m/m2
• Storage: in a dry place, from -10°C to +50°C, upright, free from pressure

FEATURES AND BENEFITS

Ceresit Reinforcing mesh designed for use with Ceresit Ceretherm External Thermal Insulation Composite Systems.

PROPERTIES

• Alkali-resistant
• Slipproof
• Tearproof

Scope of Use

This reinforcing mesh embeds into reinforcing mortars within Ceresit CT325 External Thermal Insulation Composite Systems (ETICS). For façades or pedestals exposed to higher mechanical loads, it is recommended to use CT 325 in two layers or a higher density mesh of 330 g/m².

Application

1. Spread the prepared Ceresit reinforcing mortar evenly over the surface of the boards using a toothed trowel with 10-12mm teeth.
2. For mineral wool boards, apply a "priming" layer of mortar before distributing the main layer.
3. Immediately place the fiberglass mesh onto the prepared layer.
4. Embed the mesh using a metal trowel, smoothing it out completely. The properly applied mesh should not be visible and should be fully embedded in the mortar.
5. Ensure mesh overlaps on adjacent strips by about 10 cm. Avoid aligning mesh overlaps with the joints between the panels.
6. For corner holes in the walls (e.g., windows), embed additional mesh pieces diagonally, measuring approximately 20 x 30 cm.
