Ravatherm SW A2 56mm Upstand Board

The 56mm Ravatherm SW A2 Upstand combines Ravago stone wool insulation with a 6mm fibre cement layer, engineered for vertical installation as an upstand board in inverted roof systems. This product meets current Approved Document B requirements of the Building Regulations, which mandate non-combustible materials for external wall attachments on buildings exceeding 11m in height. Tested to EN 13501‑1, it achieves Euroclass A2‑s1, d0 Reaction to Fire classification.

Key Benefits

• Length: 1200mm
• Width: 600mm
• Overall Thickness: 56mm ( 6mm fibre cement flat sheet. Insulation is 50mm mineral wool )
• Pack Quantity: 42
• Board Coverage: 0.72m2
• Pack Coverage: 30.24m2
• Weight/m2: 13.8kg
• Pack Weight: 417.31kg
• Thermal Conductivity: 0.035 W/m.K
• R-Value: 1.43m2K/W
• Density: 110 kg/m3
• Compressive strength @10% deformation: ≥ 20 kPa
• Fire Rating (Reaction to Fire): A1
• Surface finish: 6mm fibre cement flat sheet

Characteristics

1. 50mm Mineral wool Insulation
2. 6mm fibre cement surface layer
3. Euroclass A2 fire-rated
4. Excellent thermal insulation
5. Fully non-combustible
6. Rigid with high dimensional stability
7. Resistant to rot and degradation

Application

• Ideal for upstands in inverted roof systems

Manufactured through advanced extrusion technology, the 56mm Ravatherm SW A2 board delivers a closed-cell structure and smooth extrusion skin for superior strength and long-term durability. The range includes multiple thickness options and compressive strength grades, incorporating innovative low-GWP CO₂ and HFO blowing agent technology.

Enhance your building's thermal performance with the 56mm Ravatherm SW A2 – the dependable solution for UK flat roof insulation applications.
